CEM3340 VCO (Voltage Controlled Oscillator) designs

Posted by & filed under Memorymoog, MKS-80, Moog, OB-Xa, Oberheim, Oscillators, Prophet 5, Prophet T8, Roland, Sequential, SH-101, Synth DIY, Vintage synths.

To celebrate the 2016 return of the CEM3340 chip, I thought I’d do another page in my series looking at how various synths implemented classic synth chips (the others being CEM3320 Filter designs and SSM2044 LP Filter designs). This is especially useful right now, since many people have bought a few CEM3340s or V3340s or AS3340s for their own use and are looking around for circuits to use them in. If that’s your purpose, note that these are all synth voicecard circuits, so… Read more »

SH-101 replacement processor – a feasibility study

Posted by & filed under Roland, SH-101, Synth DIY, Vintage synths.

The Roland SH-101 is a late-era analogue monosynth which uses a microprocessor to perform keyboard scanning and various related functions, much like the Sequential Pro-One. Since the original uP is a 40-pin DIP, it would be possible to replace it with a more modern 40-pin DIP uP, like the PIC 16F777, or with a modern surface-mount processor on a daughter board. This page is a look at the feasibility of this idea. Original Processor pins and functions The datasheet for the… Read more »

MIDI clock to analog gate pulses

Posted by & filed under Projects, Synth DIY.

How do you synchronise your modular synth with MIDI equipment? MIDI provides the MIDI clock message, but you need something to convert this to a format an analog modular synth can understand. Most MIDI-to-CV convertors will do the job, but that can be expensive. Here’s a cheap way to do it. The Druid MIDICLK chip converts MIDI clock signals into 0-5V analog pulses. It provides two separate analog clock outputs, which can be set at various division ratios of the… Read more »

RC Filtering for SSM2164 CVs fed from DACs

Posted by & filed under Filters, Synth DIY, VCAs + Amplifiers.

I typically use the 12-bit MCP4822 DAC to produce a CV for the SSM2164 (or CoolAudio V2164, it’s the same thing) . This is a good, cheap combination. However, the 4822 produces an output of 0-4.095V, whereas the 2164 needs 0-3.3V. It is possible to use a simple voltage divider to reduce the voltage to the correct level, and it is also possible to add a capacitor to give an RC 6dB/Oct rolloff whilst we’re doing it. However, it’s not… Read more »

Investigations into what a BBD Chorus unit *really* does

Posted by & filed under BBDs+Delays, Chorus, Flanger, Stompbox stuff, Synth DIY.

I’ve been curious about Chorus for a while, since I’ve been working on and off with chorus design myself. There were a few things I didn’t understand, like what the relationshp is between the modulation LFO’s waveshape and the frequency modulation of signals going through the chorus. You’d think that if you use a sinewave to modulate the BBD clock, you’d get a sinewave modulation of frequency, right? Wrong! So what do you get? At this point, I realised that… Read more »

Fourier Analysis for non-mathematicians

Posted by & filed under Synth DIY.

Years ago, I discovered that it was possible to analyze a waveform and discover what harmonic components it was composed of, and that the magical technique to do this was called “Fourier Analysis”. I tried to find out all I could, but all the references I could find were aimed at university level mathematicians, and I was only 12 or 13. As far as I could see, none of the books explained the technique, rather they just splurged unhelpful equations… Read more »

Single VCA crossfader

Posted by & filed under Projects, Synth DIY, VCAs + Amplifiers.

There are a number of situations where it is useful to be able to crossfade between two different signals with a single control. Examples might be a wet/dry control on a delay effect, or a waveform knob on an oscillator that goes from ramp to square continuously. The simple and obvious way to do this is with a dual-gang pot. Each gang controls one signal, and it’s easy to wire so that as one increases in level, the other decreases,… Read more »

Voltage Controlled Looping Envelope Generator

Posted by & filed under Envelope Generators, Projects, Synth DIY.

This project is a development of my earlier VCADSR envelope generator. Whilst that chip had both GATE and TRIGGER inputs, this chip replaces the TRIGGER input with a MODE CV that allows selection of normal ADSR, Gated looping, or full LFO-style Looping modes. Standard ADSR mode generates the shape you expect, and allows CV control of envelope depth and overall time. Gated looping mode loops while the Gate is high. When the Gate goes low, the envelope goes to the… Read more »

Voltage-controlled digital oscillator VCDO1

Posted by & filed under Projects, Synth DIY.

A single chip 1V/Oct voltage controlled digital oscillator, with 20 waveforms in a scannable wavetable. The VCDO uses a PIC 16F1847 microprocessor to create a versatile and simple voltage-controlled 8-bit digital wavetable oscillator. All oscillator parameters are controlled by 0-5V control voltages. The chip has a native exponential control response, making interfacing with 1V/Oct control voltages very simple, even without an exponential convertor. Scanning through the wavetable with the Waveform knob. Sub Osc is a simple sine 2 octs down:… Read more »

Tap Tempo LFO (TAPLFO V2D)

Posted by & filed under Projects, Synth DIY.

2018 Note: Obsolete! This chip has been superseded by the TAPLFO 3 The new chip adds several features, has additional waveforms and improved resolution, and also no longer requires a crystal. It’s an improvement in pretty much every way! Head over and check out the data sheet. This simple Tap Tempo LFO is based on the PIC 16F684. You can set the LFO frequency by tapping a tempo on a button connected to the chip, or by changing the Tempo CV…. Read more »
