In the last six months, we’ve been very busy here in the Druid workshop, developing and testing new versions of our PIC-based chips. This work is now complete, so I’d like to introduce the new chips. Why bother? What was wrong with the old ones? Ok, there wasn’t anything much wrong with the old ones, […]
Category: Projects
In general, we’re trying to keep noise out of our circuits. Somewhat inspired by this thread on DIYStompboxes, I thought it might be fun to build a circuit that could generate that “vintage background noise” sound so that I could make things sound like they’re being played back off a phonograph cylinder or an ancient […]
Flangers are generally regarded as one of the most complicated pedals to build. A typical design has tons of chips and lots of circuit elements. Flangelicious isn’t like that. By using a microprocessor to generate an LFO-modulated clock signal directly, we can get rid of a lot of the non-signal path stuff and add features whilst we’re about it. […]
Recently I’ve been working on a four second digital delay with tap tempo and delay trails. There are lots of digital delay projects already, but the vast majority of them are based on the PT2399, which limits both the length of the delay and the sound quality. A quick summary of the features: 0 […]
What’s a “compander”? It’s a simple way to make your circuit quieter! So how does it work? Let’s say we’ve got a fairly noisy effect, like a BBD. The basic idea is that you make quiet signals louder before you put them through the effect, and then you make them quiet again after the effect, […]
How do you synchronise your modular synth with MIDI equipment? MIDI provides the MIDI clock message, but you need something to convert this to a format an analog modular synth can understand. Most MIDI-to-CV convertors will do the job, but that can be expensive. Here’s a cheap way to do it. The Druid MIDICLK chip […]
There are a number of situations where it is useful to be able to crossfade between two different signals with a single control. Examples might be a wet/dry control on a delay effect, or a waveform knob on an oscillator that goes from ramp to square continuously. The simple and obvious way to do this […]
This project is a development of my earlier VCADSR envelope generator. Whilst that chip had both GATE and TRIGGER inputs, this chip replaces the TRIGGER input with a MODE CV that allows selection of normal ADSR, Gated looping, or full LFO-style Looping modes. Standard ADSR mode generates the shape you expect, and allows CV control […]
A single chip 1V/Oct voltage controlled digital oscillator, with 20 waveforms in a scannable wavetable. The VCDO uses a PIC 16F1847 microprocessor to create a versatile and simple voltage-controlled 8-bit digital wavetable oscillator. All oscillator parameters are controlled by 0-5V control voltages. The chip has a native exponential control response, making interfacing with 1V/Oct control […]
2018 Note: Obsolete! This chip has been superseded by the TAPLFO 3 The new chip adds several features, has additional waveforms and improved resolution, and also no longer requires a crystal. It’s an improvement in pretty much every way! Head over and check out the data sheet. This simple Tap Tempo LFO is based on the […]
